he Sonel LKZ-2500 Start is a cable and underground utility locator kit. It finds buried power, telecom, water, gas and heating services, traces their route and records it on your phone, so you can dig safely and avoid costly strikes.
For Electrical contractors, telecom and fibre installers, water and drainage crews, gas and heating services, surveyors, railway and civil construction teams.
Sonel LKZ-2500 Start Cable and Underground Utility Locator
Know what’s underground before you dig. The LKZ-2500 Start is a two-part locating kit that finds buried services, follows their route and records the path, so you can plan excavations with confidence and avoid damaging live infrastructure.
How it works
The kit pairs the LKN-2500 transmitter with the LKD-2500 detector. The transmitter puts a tracing signal onto the buried service. You walk the route with the detector, which picks up the signal and shows its direction and strength. The detector connects to the Sonel LKZ Mobile app on your phone, so you can follow the compass reading and signal level live.
What it can locate
Power, control and telecommunications cables
Lightning protection and cathodic protection earthing systems
Water and sewer pipes
Gas and fuel pipelines
Heating systems and pre-insulated pipes
Three ways to apply the signal
Direct connection: connect the supplied leads and crocodile clips straight to the conductor.
Clamp: clip an optional transmitting clamp around the cable, with no need to disconnect anything.
Inductive: the transmitter’s built-in antenna induces the signal into the service from above ground.
Active and passive modes
Active mode (with the transmitter) works at 8 kHz and 32 kHz.
Passive mode (detector only) picks up 50/60 Hz mains signals and radio signals from 2 to 65 kHz. This is useful for a quick survey when you can’t connect a transmitter.
Record and share your routes
The Sonel LKZ Mobile app logs your traced route with GPS waypoints and notes on each point. You can:
watch your position live
measure the distance to any waypoint
merge routes
review all recorded readings
export routes to other phones, including those of colleagues without an LKZ kit
Electrical contractors, telecom and fibre installers, water and drainage crews, gas and heating services, surveyors, railway and civil construction teams.
What’s in the box
LKN-2500 transmitter and LKD-2500 detector
Sonel LKZ Mobile app
5 m test leads, red and blue (1 kV)
3 red and 1 blue crocodile clips (1 kV, 20 A)
2 earth spikes (30 cm)
Power supplies and mains charging cables
Carry bag, shoulder harness, long handle and control panel holder
Declaration of verification
Optional accessories
LKR-2500 A-Frame detector, for locating cable sheath faults
Transmitting clamps (52 mm, 110 mm and 125 mm)
Tracing wire for non-metallic pipes (50 m or 80 m reels)
LKZ-2500 START Cable and underground infrastructure locator WMGBLKZ2500START
Get A Quote
he Sonel LKZ-2500 Start is a cable and underground utility locator kit. It finds buried power, telecom, water, gas and heating services, traces their route and records it on your phone, so you can dig safely and avoid costly strikes.
For Electrical contractors, telecom and fibre installers, water and drainage crews, gas and heating services, surveyors, railway and civil construction teams.
Description
Sonel LKZ-2500 Start Cable and Underground Utility Locator
Know what’s underground before you dig. The LKZ-2500 Start is a two-part locating kit that finds buried services, follows their route and records the path, so you can plan excavations with confidence and avoid damaging live infrastructure.
How it works
The kit pairs the LKN-2500 transmitter with the LKD-2500 detector. The transmitter puts a tracing signal onto the buried service. You walk the route with the detector, which picks up the signal and shows its direction and strength. The detector connects to the Sonel LKZ Mobile app on your phone, so you can follow the compass reading and signal level live.
What it can locate
Three ways to apply the signal
Active and passive modes
Record and share your routes
The Sonel LKZ Mobile app logs your traced route with GPS waypoints and notes on each point. You can:
Built for the field
Who uses it
Electrical contractors, telecom and fibre installers, water and drainage crews, gas and heating services, surveyors, railway and civil construction teams.
What’s in the box
Optional accessories
LKZ-2500 User Manual
LKZ-2500 Data Sheet
